250 mkm bo'lgan tolalar yuqori modulli plastmassadan yasalgan bo'sh trubkada joylashgan. Quvurlar suvga chidamli plomba aralashmasi bilan to'ldiriladi. Elyaf bilan mustahkamlangan plastmassa (FRP) metall bo'lmagan mustahkamlik elementi sifatida yadro markazida joylashgan. Quvurlar (va plomba moddalari) mustahkamlik elementi atrofida ixcham va dumaloq yadroga o'ralgan. Kabel yadrosi atrofida alyuminiy polietilen laminat (APL) namlik to'sig'i qo'yilgandan so'ng, simi pe qoplamasi bilan to'ldiriladi.

Xususiyatlari

· Yaxshi mexanik va harorat ko'rsatkichlari

· Gidrolizga chidamli yuqori quvvatli bo'sh trubka

· Maxsus naychali plomba aralashmasi tolaning muhim himoyasini ta'minlaydi

· Maxsus mo'ljallangan ixcham struktura bo'shashgan quvurlarning qisqarishini oldini olishda yaxshi

· PE qobig'i kabelni ultrabinafsha nurlanishidan himoya qiladi

· Kabelning suv o'tkazmasligini ta'minlash uchun quyidagi choralar ko'riladi:

- Markaziy quvvat elementi sifatida yagona tolali mustahkamlangan plastmassa

- Bo'shashgan naychani to'ldirish aralashmasi

Kabel yadrosi - 100 foizga to‘ldi

- APL namlik to'sig'i

Standartlar

GYFTA kabeli standart YD/T 901-2001va IEC 60794-1 standartlariga mos keladi.

Optik xususiyatlar

		G.652	G.655	50/125μm	62.5/125μm
Zaiflash (plyus 20 daraja)	@850nm			3.0 dB/km dan kam yoki unga teng	3.0 dB/km dan kam yoki unga teng
	@1300nm			1.0 dB/km dan kam yoki unga teng	1.0 dB/km dan kam yoki unga teng
	@1310nm	0,36 dB/km dan kam yoki unga teng	0.40 dB/km dan kam yoki unga teng
	@1550nm	0.22 dB/km dan kam yoki unga teng	0.23dB/km dan kam yoki unga teng
Tarmoqli kengligi (A sinfi)	@850nm			500 MHz·km dan katta yoki unga teng	200 MHz·km dan katta yoki unga teng
Tarmoqli kengligi (A sinfi)	@1300nm			1000 MHz·km dan katta yoki unga teng	600 MHz·km dan katta yoki unga teng
Raqamli diafragma				{0}}.200±0,015NA	{0}},275±0,015NA
Kabelni kesish to'lqin uzunligi		1260nm dan kam yoki unga teng	1480nm dan kam yoki unga teng

Texnik parametrlar

Kabel turi	Elyaflar soni	Quvurlar	To'ldiruvchilar	Kabel diametri mm	Kabelning og'irligi kg/km	Mustahkamlik chegarasi Uzoq/Qisqa muddatli N	Siqilish qarshiligi Uzoq/Qisqa muddatli N/100 mm	Bükme radiusi Statik/dinamik mm
GYFTA-2~6	2~6	1	5	11.4	108	400/1000	300/1000	10D/20D
GYFTA-8~12	8~12	2	4	11.4	108	400/1000	300/1000	10D/20D
GYFTA-14~18	14~18	3	3	11.4	108	400/1000	300/1000	10D/20D
GYFTA-20~24	20~24	4	2	11.4	108	400/1000	300/1000	10D/20D
GYFTA-26~30	26~30	5	1	11.4	108	400/1000	300/1000	10D/20D
GYFTA-32~36	32~36	6	0	11.4	108	400/1000	300/1000	10D/20D
GYFTA-2~12	2~12	1	5	12.8	134	600/1500	300/1000	10D/20D
GYFTA-14~24	14~24	2	4	12.8	134	600/1500	300/1000	10D/20D
GYFTA-26~36	26~36	3	3	12.8	134	600/1500	300/1000	10D/20D
GYFTA-38~48	38~48	4	2	12.8	134	600/1500	300/1000	10D/20D
GYFTA-50~60	50~60	5	1	12.8	134	600/1500	300/1000	10D/20D
GYFTA-62~72	62~72	6	0	12.8	134	600/1500	300/1000	10D/20D
GYFTA-2~6	2~6	1	7	12.8	140	1000/3000	300/1000	10D/20D
GYFTA-8~12	8~12	2	6	12.8	140	1000/3000	300/1000	10D/20D
GYFTA-14~18	14~18	3	5	12.8	140	1000/3000	300/1000	10D/20D
GYFTA-20~24	20~24	4	4	12.8	140	1000/3000	300/1000	10D/20D
GYFTA-26~30	26~30	5	3	12.8	140	1000/3000	300/1000	10D/20D
GYFTA-32~36	32~36	6	2	12.8	140	1000/3000	300/1000	10D/20D
GYFTA-38~42	38~42	7	1	12.8	140	1000/3000	300/1000	10D/20D
GYFTA-44~48	44~48	8	0	12.8	140	1000/3000	300/1000	10D/20D
GYFTA-50~60	50~60	5	3	14.8	176	1000/3000	300/1000	10D/20D
GYFTA-62~72	62~72	6	2	14.8	176	1000/3000	300/1000	10D/20D
GYFTA-74~84	74~84	7	1	14.8	176	1000/3000	300/1000	10D/20D
GYFTA-86~96	86~96	8	0	14.8	176	1000/3000	300/1000	10D/20D
GYFTA-98~108	98~108	9	1	17.1	226	1000/3000	300/1000	10D/20D
GYFTA-110~120	110~120	10	0	17.1	226	1000/3000	300/1000	10D/20D
GYFTA-122~132	122~132	11	1	19.2	279	1000/3000	300/1000	10D/20D
GYFTA-134~144	134~144	12	0	19.2	279	1000/3000	300/1000	10D/20D
